Home>PoE Camera System>Poe NVR Kit>H.265 8CH UHD 4K POE Security Camera System AI 8MP PTZ Camera CCTV Video Surveillance Kit Human Detect Auto Tracking
H.265 8CH UHD 4K POE Security Camera System AI 8MP PTZ Camera CCTV Video Surveillance Kit Human Detect Auto Tracking

H.265 8CH UHD 4K POE Security Camera System AI 8MP PTZ Camera CCTV Video Surveillance Kit Human Detect Auto Tracking

Item NO.: 6108K-PT825-80P
Similar Style
H.265 8CH UHD 4K POE Security Camera System AI 8MP PTZ Camera CCTV Video Surveillance Kit Human Detect Auto Tracking Ultra HD 4K POE Camera System 16CH H.265 Smart AI PTZ Camera Human Detection Auto Tracking 8MP Security Surveillance Kit 8MP POE Security Camera Outdoor Camera PTZ Mobile Monitoring Auto Tracking Human Detection Surveillance Kit
Style
8CH 8 cameras kit 8CH 6 cameras kit 8CH 4 cameras kit 8CH 2 cameras kit

Detail

  • Product NameH.265 8CH UHD 4K POE Security Camera System AI 8MP PTZ Camera CCTV Video Surveillance Kit Human Detect Auto Tracking
  • Item NO.6108K-PT825-80P
  • Weight11.0000 kg = 24.2508 lb = 388.0136 oz
  • CategoryPoE Camera System> Poe NVR Kit
  • BrandTinosec
  • Creation Time2023-07-20
  • 1 x 8CH 4K PoE NVR
  • 2/4/6/8 x 8MP PoE IP Cameras.
  • 1 x Power Supply for NVR.
  • 1 x USB Mouse for NVR.
  • 1 x Remote Contorller for NVR.
  • 1 x Network Cable for NVR.
  • 2/4/6/8 x 20M Network Cable for Cameras.
  • 1 x User Manual.
  • 2/4/6/8 x Screw bags.
  • 2 x Warning Sticker (gift).
  • 2/4/6/8 x Waterproof Connector for Cable (gift).

Support 4K 8MP HD Display

Show Higher-Quality Images, With Better Experience.

PTZ Control by APP

355 Degree PTZ pan/tilt rotation vertical 90 Degree, control the rotation angle through App.

Motion Auto tracking

After locking the target, the camera will adjust the pan rotation automatically, Tracking Moving Objects, Cars, Pets, Human, and push alerts notifications to your Smartphone.

Smart Ai Motion Detection & Human Detection

when motion is detected the NVR will save the footage into hard disk without missing any important events. You can even ensure that false alarms are avoided by setting the motion detection "mask" to block areas with constant movement.

When Someone Breaks Into Shooting Area,The Camera Will Alarm Messages Will Be Pushed To Your Phone App.

AI Humen Detection & Email Alert & Alarm Sound

Smart Ai Detection function , Monitor moving objects, automatically illuminate. support mixing line, area, two-way flow detection, for human form, easy setting in App.

Real-time Two-way Audio Communication

Camera has built in Microphone and Speaker.
Never miss a moment with your family.

Smart IR-Cut Night Vision

When The 2 White Leds Lighting, The Camera Will Show Colorful Vision At Night,

There Are Three Night Modes For You To Select.

H.265 POE CCTV System

H.265 More Clear , HD resolution offer you best image quality in a lower bit rate.

Save more storage space,can reduce 40%-50% file size,save your HDD storage space and reduce your purchase cost.

Simplify Installation,Easy To Setup

Power over Ethernet means the IP cameras connect to the NVR with a single cable that transmits both data and power, No need to connect power cable, simplified the installation and reduced costs and easy to set up.

TinoSec 48V POE CCTV System

Max support 100 meters transmission distance

IP66 Waterproof Security Camera

Our Camera All Can Suit For Both Outdoor And Indoor Usage.

Remote Access Anytime, Anywhere

Based On P2P (Peer To Peer) Technology, Support Plug-And-Play Installation.

Access The Ip Camera Through Its Web Interface Via Internet Explorer,

Also Comes With a Free Smartphone App (Android & Iphone) For Remotely View From Anywhere.

Support IOS And Android Device Access. Scan QR-Code To Login. Download Free App In Apple App Store / Google Play.


Specification
Model
XM-PT825-80P


Video
Sensor
Embedded RTOS,dual-core 32bit DSP(NT98566),pure hard compression ,watch dog
Video compression
8.0M 1/2.7"SC501AI High Quality CMOS sensor, color 0.0001Lux@F1.2, black/white 0.0001Lux@F1.2
Image output
H.265AI/H.265+(Compatible with H.265/H.264), support dual stream, AVI;0.1M~8Mpbs variable;1~30f/s variable
Shutter
1/50(1/60) s to 1/10,000s
Noise reduction
Support 2D/3D
Wide dynamic
Support digital
Lens
3.6mm
Day and night
Support IR-CUT, IR-CUT coil has an internal resistance of 20 ohms, the power-on time is less than 200ma, and thevoltageis3.5V-6V
IR distance
20-30m
Audio
Audio compression
G.711, support bidirectional talk,audio&video synchronization
Audio interface
build in micphone and speaker


PTZ
Pan 355 degree Tilt 90 degree
Auto Human Tracking
Internet
Port
1*RJ45 10/100M adaptive Ethernet port; support RTSP/FTPDHCP/NTP/UPnP etc


Alarm
Human detection, Motion detection, AI alarm.
Alarm Notification Push, Voice Alarm, Video Record, Snap Picture
Red Blue Light Alarm


Recording
Time video, Event video
Time play back, Event play back
SD Card, up to 128GB. Cloud Storage


Other
Reliability
Comprehensive lightning protection, 7 * 24 hours 65 ℃ high temperature stable and reliable testing
ON-VIF
Support
Mobile monitoring
Support multiple mobile monitoring(iOS,Android)
Power
POE48V/DC12V 1A
Reset
Supports one-click reset
Environmental conditions
Temperature
-20℃ to +55℃
Humidity
30% to 80% RH
System
Main processor
Hi3536E
Operating System
Embedded Linux
System resources
Simultaneous multi-channel real-time
recording, playback, network operation,
USB backup
Interface
Operator interface
16-bit true color graphic menu operation
interface, support mouse operation
Preview
1/2/4/6/8/9/16
Video
Video input (IP)
16*4K(Access bandwidth 72Mbps)
Video compression
H.265AI/H.265+(compatible H.265/H.264)
Display quality
Max:4K
Playback quality
4K/5M/4M/3M/1080P
VR
Unsupport
human shape / Face
Support(depend on camera)
Audio
Audio compression
G.711A
Intercom
unsupport
Record
&
playback
Recording mode
Manual>Alarm>Dynamic Detection>Timing
Localpayback(real-time+ Un
real-time)
4K(1*real-time)/5M(1+1)/4M(2+1)/
3M(3+1)/1080P(5+1)
Search mode
Search by Time/Calendar/Event/Channel/Face
Record storage
HDD、Network
Backup mode
Network backup, USB hard disk, USB burner,
SATA burner
External
interface
Video output
1ch VGA,1ch  HD output
Audio I/O
0/1(3.5MM audio output)
Alarm I/O
0/0
Network interface
1*RJ45 10M/100M Adaptive Ethernet port
USB interface
2*USB2.0 ports(one USB extension
interface is reserved)
HDD
1 SATA(Up to 14TB for each disk)
ESATA
No
Serial interface
No
Other
ONVIF
Support
Power supply
12V/2A
Power Consumption
<10W(Without HDD)
Work environment
Temperature:0℃ -55℃ ,
Humidity:10%-90%RH , Atm:86kpa-106kp




Company Profile
FAQ
Q: What is your company’s competitive advantage?
A: 1)TinoSec is a professional manufacturer of R&D, Production, and Marketing (3 in 1) in security camera system more than 10 years.
2).Certificates:CE,FCC,RoHS and ect.
3).Service:OEM/ODM orders are welcomed!

Q: How about your company's production capacity?A: Complete HD Camera: 5,000pcs/Week.

Q: What's the MOQ?A: Online order:No moq,OEM/ODM:Our minimum order qty is 50pcs each model, but we support small test order for all customer.

Q: What is your delivery time?Complete HD Camera system:1) Within 3-5 working days for samples order,2) Within 7-15 working days for bulk order.

Q: What shipping method can i choose? How about the shipping time?1) For RU / CZ order, by local express about 1-3 days.2)For small order, by air express like DHL, UPS, TNT, FedEx and etc, about 3-7days.3)For big order, by air about 7-12 days, by sea about 15-35 days.

Q: How about your warranty?A: Warranty is 24 months, life-time maintain!

Q:What is your method of payment?A:Support T/T, LC, Western Union, Paypal, Trade Assurance and more.
