Package List:
1 * 4MP Wireless IP Camera
1 * 5V2A power(EU/UK/AU/US PMoptional)
1 * User Manual
1 * Screw bag
(TF card 32GB/64GB optional)
Note: The power supply fo this camera is 5V2A! the camera will be damaged if you use other power supply.
HD 4MP Resolution
Capture more clear images
PTZ Remote Control
Rotates 355° Horizontally and 90° Vertically. You can control it in the iCsee APP directly whenever you want and wherever you are.
Humanoid Detection & APP Push Alert & Email Alert
When someone breaks into shooting area, the camera will emits a sound to scare off intruders (customizable alarm sound). And it will push the alarm message to your mobile APP, then 4 white LED lights illuminate the intruder.
High-precision Alarm Mechanism
Alarm only when human movement is detected.
Support Humanoid Auto Tracking and Smart Daemon Position
When somebody move, the camera automatically track the body, don't miss any corner. When human disappears from the camera's field of view, the camera will automatically rotate to the daemon position you set.
DIY Alarm Voice And Default Bell
Support default bell or DIY 3 seconds custom alarm bell with your voice. When you go out without bringing your phone, someone close to your house, the DIY alarm voice could let the men think you are looking at him now.
Real-time Two-way Audio Communication
The camera has a built-in microphone and speaker so you can talk to people anytime, anywhere.
Full Color Night Vision
When the camera triggers an alarm, the white LED lights illuminate to provide a colorful surveillance picture.
IP66 Outdoor Waterproof / Dustproof
The shell is made of high-grade plastic , which is waterproof, sun-proof and dust-proof. It is suitable for any environment.
P2P Multi-User Remote Access.
Thanks to the convenient P2P technology, now you can view the live footage whenever you want to, just log in the P2P account on the app via your Smartphone or tablet and start monitoring your house in no time.
Two Flexible & Secure Storage Options
The camera supports up to 128GB TF card local backup and also provides cloud storage service(Need to pay extra cost).
Two Kinds of Storage Methods
This camera support local TF card storage and cloud storage.
Easy To Connect on APP iCsee
Two kinds of installation methods
Model
|
Model Type:
|
PTZ WIFI Camera
|
Model No.
|
XM-PT805-40W
|
System
|
System structure
|
ICSEE RTOS design, dual-core 32-bit DSP (GK7202V300), pure hard compression, watchdog
|
Video
|
Sensor
|
4 million high-performance CMOS sensors; Color 0.01Lux@F1.2 , black and white 0.001Lux@F1.2
|
Video processing
|
H. 265ai encoding, dual bitstream, avi format; Code stream 0.1m~8mpbs adjustable; Frame rate 1~30 frames / s adjustable
|
Image output
|
Main code stream:2560*1440@12fps ; Sub code stream: 800*448@12fps
|
Shutter
|
1/50(1/60)to 1/10000 of a second
|
Noise reduction
|
2 d / 3 d noise reduction
|
Wide dynamic
|
Digital-wide dynamic
|
Lens
|
3.6mm hd lens
|
Night vision
|
IR-CUT,Infrared night vision, color filter automatically switch
|
light distance
|
Infrared 15m, white light 15m (4 white light,4 infrared light)
|
Audio
|
Audio processing
|
G.711A,two way audio
|
Audio interface
|
-33DB high sensitive MIC,8 euro 1 watt high quality waterproof speaker
|
PTZ
|
|
pan 355 degree,tilt 90 degree
|
|
Human tracking, guard position
|
Network
|
Network interface
|
One RJ45 Ethernet port,10/100M auto-sensing
|
WIFI antenna interface
|
2.4g dual WIFI antenna
|
Alarm
|
|
Human detection, motion detection, smart AI alarm
|
|
APP push, voice alarm, video recording, capture pictures
|
|
High power red and blue light alarm
|
Video
|
Video mode
|
Timing video, event video
|
Playback mode
|
Event playback, time playback
|
Storage
|
Storage
|
Local TF card, up to 128G; Cloud storage
|
Other
|
Reliability
|
Comprehensive lightning protection,7*24 hours 65℃ high temperature test is stable and reliable
|
ONVIF
|
support
|
Cell phone monitoring
|
Mobile phone monitoring (iOS, Android)
|
power
|
DC5V/2A
|
Material
|
ABS
|
Reset
|
Support one-button reset function
|
Work environment
|
Temperature
|
-20℃ to +55℃
|
Humidity
|
30% to 80% RH
|
Q: What is your company’s competitive advantage?
A: 1)TinoSec is a professional manufacturer of R&D, Production, and Marketing (3 in 1) in security camera system more than 10years.
2).Certificates:CE,FCC,RoHS and ect.
3).Service:OEM/ODM orders are welcomed!
Q: How about your company's production capacity?
A: Complete HD Camera: 5,000pcs/Week.
Q: What's the MOQ?
A: Online order:No moq,
OEM/ODM:Our minimum order qty is 50pcs each model, but we support small test order for all customer.
Q: What is your delivery time?Complete HD Camera system:
1) Within 3-5 working days for samples order,
2) Within 7-15 working days for bulk order.
Q: What shipping method can i choose? How about the shipping time?
1) For RU / CZ order, by local express about 1-3 days.
2)For small order, by air express like DHL, UPS, TNT, FedEx and etc, about 3-7days.
3)For big order, by air about 7-12 days, by sea about 15-35 days.
Q: How about your warranty?
A: Warranty is 24 months, life-time maintain!
Q:What is your method of payment?
A:Support T/T, LC, Western Union, Paypal, Trade Assurance and more.
